IK-1-IMX-5

The IK-1-IMX-5 is a breakout board for rapid prototyping using the IMX-5.The IMX-5 is a 10-DOF sensor module consisting of a tactical grade Inertial Measurement Unit (IMU), magnetometer, and barometer. Output includes angular rate, linear acceleration, magnetic vector, and barometric pressure and altitude. IMU calibration consists of bias, scale factor, cross-axis alignment, and temperature compensation.

The IMX-5 includes Attitude Heading Reference System (AHRS) sensor fusion to estimate roll, pitch, and heading. Adding GNSS input to the IMX-5 enables onboard Inertial Navigation System (INS) sensor fusion for roll, pitch, heading, velocity, and position.
